Diamond Ground Piranha™ III Tungsten Grinder DGP-PG3-A

Genuine Diamond Ground Piranha™ III tungsten grinder features a universal collet that accepts .040 through 3/16 diameter tungsten welding electrode. It also has enhanced safety provided by a sliding dust shield for 100% dust containment. The Pirhana III's on/off switch with LED light gives clear visual indication that the unit is turned on. The chassis weighs only 38 lbs. and features a recessed handle, integrated receptacle for holding tungsten electrodes, and blue powder coat finish.

Why use a dedicated tungsten grinder

Safety: Enclosed grinding area captures Tungsten dust for easy disposal.

Weld Quality: 20 Ra surface finish improves Tungsten life, arc starting, arc stability and produces consistent weld penetration.

Productivity: Longitudinally diamond grind your Tungsten electrode in less than 30 seconds correctly and consistently.

Value: The PIRANHA III diamond grinds, flats and notches your Tungsten economically.

For .040" through 3/16" diameter tungsten electrode.

Features

Sliding dust shield for 100% dust containment

Easy set-up, optimal consistency and near-perfect repeatability.

Compact, durable and solid design with no vibration.

Longitudinal 20 RA grinding for maximum arc starting, arc stability, electrode life & weld penetration.

Universal collet arm for 6 electrode sizes - 040" (1.0mm), 1/16" (1.6mm), 3/32" (2.4mm),1/8" (3.2mm) ,5/32" (4.0mm) & 3/16" (4.8mm) - with no equipment changes.

Included angle scale for angles from 10 degrees - 60 degrees

Precision tip flat gauge & depth adjustment stop ensures exact tungsten points every time - enabling consistent, repeatable arc performance and welding output.

Containment baffle to keep dust inside the grinder housing, for safety and easy disposal.

Tip flat block for square end grinding and removing bad tips.

Electrode notching station for simple cut-off.

Integrated receptacle area for ease of handling electrodes

Recessed handle for better form & function

On/off switch with LED light for improved display of unit operation

Lightened chassis for reduced weight

Signature blue powdercoat

Vacuum-port ready

Detailed manual for valuable engineering data and welding recommendations.

Specs

Range of Included Angle: 10 degrees - 60 degrees

Electrode Diameters: 040"(1.0mm),1/16" (1.6mm), 3/32" (2.4mm),1/8" (3.2mm) , 5/32" (4.0mm) & 3/16" (4.8mm)

Minimum Electrode Length: 1.75" ( 44.5mm)

Voltage: 100/120 VAC, 50/60Hz

Power Consumption: 500 Watts

Motor: 1/10 hp, 3000rpm, 2.5 amps

Length: 13.5" (342mm)

Width: 7.0" (177mm)

Height: 9.5" (240mm)

Weight: 46 lbs (20.87kg)
